Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4826610
Gene symbol: Ncan
Gene name: neurocan
Probe: T63368
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_015922_01: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: neural retina Weak Regionally restricted euxassay_015922_01
Specimen euxassay_015922_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: neural retina Weak Regionally restricted euxassay_015922_02
TS23: telencephalon Strong Uniform euxassay_015922_02
Specimen euxassay_015922_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: neural retina Weak Regionally restricted euxassay_015922_03
TS23: telencephalon Strong Uniform euxassay_015922_03
Specimen euxassay_015922_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Weak Regionally restricted euxassay_015922_04
TS23: telencephalon Strong Uniform euxassay_015922_04
Specimen euxassay_015922_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Weak Regionally restricted euxassay_015922_05
TS23: facial ganglion Weak Regionally restricted euxassay_015922_05
TS23: telencephalon Strong Uniform euxassay_015922_05
TS23: hindbrain Strong Uniform euxassay_015922_05
Specimen euxassay_015922_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Weak Regionally restricted euxassay_015922_06
TS23: facial ganglion Weak Regionally restricted euxassay_015922_06
TS23: hindbrain Strong Uniform euxassay_015922_06
TS23: telencephalon Strong Uniform euxassay_015922_06
Specimen euxassay_015922_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Weak Regionally restricted euxassay_015922_07
TS23: facial ganglion Weak Regionally restricted euxassay_015922_07
TS23: vestibulo-cochlear ganglion Weak Regionally restricted euxassay_015922_07
TS23: telencephalon Strong Uniform euxassay_015922_07
TS23: hindbrain Strong Uniform euxassay_015922_07
Specimen euxassay_015922_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Weak Regionally restricted euxassay_015922_08
TS23: telencephalon Strong Uniform euxassay_015922_08
TS23: diencephalon Strong Uniform euxassay_015922_08
TS23: hindbrain Strong Uniform euxassay_015922_08
TS23: midbrain Strong Uniform euxassay_015922_08
Specimen euxassay_015922_09: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Weak Regionally restricted euxassay_015922_09
TS23: trigeminal nerve Weak Regionally restricted euxassay_015922_09
TS23: dorsal root ganglion Weak Regionally restricted euxassay_015922_09
TS23: telencephalon Strong Uniform euxassay_015922_09
TS23: diencephalon Strong Uniform euxassay_015922_09
TS23: hindbrain Strong Uniform euxassay_015922_09
TS23: midbrain Strong Uniform euxassay_015922_09
Specimen euxassay_015922_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: dorsal root ganglion Weak Regionally restricted euxassay_015922_10
TS23: hindbrain Strong Uniform euxassay_015922_10
TS23: telencephalon Strong Uniform euxassay_015922_10
TS23: diencephalon Strong Uniform euxassay_015922_10
TS23: midbrain Strong Uniform euxassay_015922_10
Specimen euxassay_015922_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: dorsal root ganglion Weak Regionally restricted euxassay_015922_11
TS23: midbrain Strong Uniform euxassay_015922_11
TS23: hindbrain Strong Uniform euxassay_015922_11
TS23: telencephalon Strong Uniform euxassay_015922_11
TS23: diencephalon Strong Uniform euxassay_015922_11
Specimen euxassay_015922_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon Strong Uniform euxassay_015922_12
TS23: diencephalon Strong Uniform euxassay_015922_12
TS23: midbrain Strong Uniform euxassay_015922_12
TS23: hindbrain Strong Uniform euxassay_015922_12
TS23: ventral grey horn Strong Single cells euxassay_015922_12
Specimen euxassay_015922_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: midbrain Strong Uniform euxassay_015922_13
TS23: hindbrain Strong Uniform euxassay_015922_13
TS23: diencephalon Strong Uniform euxassay_015922_13
TS23: telencephalon Strong Uniform euxassay_015922_13
TS23: ventral grey horn Strong Single cells euxassay_015922_13
TS23: intermediate grey horn Strong Single cells euxassay_015922_13
Specimen euxassay_015922_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: midbrain Strong Uniform euxassay_015922_14
TS23: hindbrain Strong Uniform euxassay_015922_14
TS23: telencephalon Strong Uniform euxassay_015922_14
TS23: diencephalon Strong Uniform euxassay_015922_14
TS23: intermediate grey horn Strong Single cells euxassay_015922_14
TS23: ventral grey horn Strong Single cells euxassay_015922_14
Specimen euxassay_015922_15: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: dorsal root ganglion Weak Regionally restricted euxassay_015922_15
TS23: midbrain Strong Uniform euxassay_015922_15
TS23: hindbrain Strong Uniform euxassay_015922_15
TS23: telencephalon Strong Uniform euxassay_015922_15
TS23: diencephalon Strong Uniform euxassay_015922_15
TS23: ventral grey horn Strong Single cells euxassay_015922_15
Specimen euxassay_015922_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: dorsal root ganglion Weak Regionally restricted euxassay_015922_16
TS23: telencephalon Strong Uniform euxassay_015922_16
TS23: diencephalon Strong Uniform euxassay_015922_16
TS23: hindbrain Strong Uniform euxassay_015922_16
TS23: midbrain Strong Uniform euxassay_015922_16
Specimen euxassay_015922_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Weak Regionally restricted euxassay_015922_17
TS23: dorsal root ganglion Weak Regionally restricted euxassay_015922_17
TS23: hindbrain Strong Uniform euxassay_015922_17
TS23: midbrain Strong Uniform euxassay_015922_17
TS23: telencephalon Strong Uniform euxassay_015922_17
TS23: diencephalon Strong Uniform euxassay_015922_17
Specimen euxassay_015922_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vestibulo-cochlear ganglion Weak Regionally restricted euxassay_015922_18
TS23: trigeminal ganglion Weak Regionally restricted euxassay_015922_18
TS23: glossopharyngeal ganglion Weak Regionally restricted euxassay_015922_18
TS23: midbrain Strong Uniform euxassay_015922_18
TS23: hindbrain Strong Uniform euxassay_015922_18
TS23: telencephalon Strong Uniform euxassay_015922_18
TS23: diencephalon Strong Uniform euxassay_015922_18
Specimen euxassay_015922_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vestibulo-cochlear ganglion Weak Regionally restricted euxassay_015922_19
TS23: trigeminal ganglion Weak Regionally restricted euxassay_015922_19
TS23: glossopharyngeal ganglion Weak Regionally restricted euxassay_015922_19
TS23: facial ganglion Weak Regionally restricted euxassay_015922_19
TS23: telencephalon Strong Uniform euxassay_015922_19
TS23: diencephalon Strong Uniform euxassay_015922_19
TS23: hindbrain Strong Uniform euxassay_015922_19
TS23: midbrain Strong Uniform euxassay_015922_19
Specimen euxassay_015922_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Weak Regionally restricted euxassay_015922_20
TS23: facial ganglion Weak Regionally restricted euxassay_015922_20
TS23: telencephalon Strong Uniform euxassay_015922_20
TS23: hindbrain Strong Uniform euxassay_015922_20
TS23: midbrain Strong Uniform euxassay_015922_20
Specimen euxassay_015922_21: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Weak Regionally restricted euxassay_015922_21
TS23: facial ganglion Weak Regionally restricted euxassay_015922_21
TS23: telencephalon Strong Uniform euxassay_015922_21
TS23: hindbrain Strong Uniform euxassay_015922_21
TS23: midbrain Strong Uniform euxassay_015922_21
Specimen euxassay_015922_22: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: neural retina Weak Regionally restricted euxassay_015922_22
TS23: trigeminal ganglion Weak Regionally restricted euxassay_015922_22
TS23: telencephalon Strong Uniform euxassay_015922_22
TS23: hindbrain Strong Uniform euxassay_015922_22
Specimen euxassay_015922_23: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: neural retina Weak Regionally restricted euxassay_015922_23
TS23: trigeminal ganglion Weak Regionally restricted euxassay_015922_23
TS23: telencephalon Strong Uniform euxassay_015922_23
TS23: hindbrain Strong Uniform euxassay_015922_23
Specimen euxassay_015922_24: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: neural retina Weak Regionally restricted euxassay_015922_24
TS23: telencephalon Strong Uniform euxassay_015922_24
