Gene Expression Data
Assay Details
Assay
Reference: J:171409 GUDMAP Consortium, GUDMAP: the GenitoUrinary Development Molecular Anatomy Project. www.gudmap.org. 2004;
Assay type: RNA in situ
MGI Accession ID: MGI:5540243
Gene symbol: Zbtb7a
Gene name: zinc finger and BTB domain containing 7a
Probe: MTF#1566
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Results
Specimen GUDMAP:6387: embryonic day 15.5 (more )
Note: Labeling was visualized using BM purple.
Structure Level Pattern Image Note
TS23: ureteric tip Absent GUDMAP:6387
TS23: ureteric trunk Absent GUDMAP:6387
TS23: renal interstitium Absent GUDMAP:6387
TS23: cap mesenchyme Absent GUDMAP:6387
TS23: early tubule Present GUDMAP:6387
TS23: late tubule Present GUDMAP:6387
TS23: renal vasculature Absent GUDMAP:6387
TS23: ureter Absent GUDMAP:6387
TS23: urethra of male Present GUDMAP:6387
TS23: bladder Present GUDMAP:6387
TS23: testis Present GUDMAP:6387
TS23: male associated reproductive structure Present GUDMAP:6387
Specimen GUDMAP:7230: postnatal day 0 (more )
Note: Labeling was visualized using BM purple.
Structure Level Pattern Image Note
TS27: loop of Henle, outer medullary portion Present GUDMAP:7230
TS27: loop of Henle, inner medullary portion Present GUDMAP:7230
TS27: distal convoluted tubule Present GUDMAP:7230
TS27: presumptive endothelium of capillary loop renal corpuscle Present GUDMAP:7230
TS27: glomerular capillary system of maturing glomerular tuft Present GUDMAP:7230
TS27: glomerular capillary system Present GUDMAP:7230
TS27: anlage of loop of Henle of cortical renal tubule Present GUDMAP:7230
TS27: outer medullary collecting duct Present GUDMAP:7230
TS27: pelvic urothelial lining Present GUDMAP:7230
TS27: urothelium of ureter Present GUDMAP:7230
TS27: inner medullary collecting duct Present GUDMAP:7230
Specimen GUDMAP:7725: postnatal day 0 (more )
Note: Labeling was visualized using BM purple.
Structure Level Pattern Image Note
TS27: renal connecting tubule Present GUDMAP:7725
TS27: renal cortical interstitium Present GUDMAP:7725
TS27: ureteric tip Present GUDMAP:7725
TS27: cortical collecting duct Present GUDMAP:7725
TS27: inner medullary collecting duct Present GUDMAP:7725
TS27: outer medullary collecting duct Present GUDMAP:7725
TS27: anlage of loop of Henle of cortical renal tubule Present GUDMAP:7725
TS27: loop of Henle, outer medullary portion Present GUDMAP:7725
TS27: loop of Henle, inner medullary portion Present GUDMAP:7725
Specimen GUDMAP:12755: embryonic day 15.5 (more )
Note: Labeling was visualized using BM purple.
Structure Level Pattern Image Note
TS23: ureteric tip Absent GUDMAP:12755
TS23: ureteric trunk Absent GUDMAP:12755
TS23: renal interstitium Present GUDMAP:12755
TS23: cap mesenchyme Absent GUDMAP:12755
TS23: early tubule Absent GUDMAP:12755
TS23: late tubule Absent GUDMAP:12755
TS23: renal vasculature Absent GUDMAP:12755
TS23: ureter Absent GUDMAP:12755
TS23: urethra of female Present GUDMAP:12755
TS23: bladder Absent GUDMAP:12755
TS23: ovary Present GUDMAP:12755
TS23: female associated reproductive structure Present GUDMAP:12755
Specimen GUDMAP:12756: embryonic day 15.5 (more )
Note: Labeling was visualized using BM purple.
Structure Level Pattern Image Note
TS23: ureteric tip Absent GUDMAP:12756
TS23: ureteric trunk Absent GUDMAP:12756
TS23: renal interstitium Present GUDMAP:12756
TS23: cap mesenchyme Absent GUDMAP:12756
TS23: early tubule Absent GUDMAP:12756
TS23: late tubule Absent GUDMAP:12756
TS23: renal vasculature Absent GUDMAP:12756
TS23: ureter Absent GUDMAP:12756
TS23: urethra of male Present GUDMAP:12756
TS23: bladder Absent GUDMAP:12756
TS23: testis Present GUDMAP:12756
TS23: male associated reproductive structure Present GUDMAP:12756
