Gene Expression Data
Assay Details
Assay
Reference: J:171409 GUDMAP Consortium, GUDMAP: the GenitoUrinary Development Molecular Anatomy Project. www.gudmap.org. 2004;
Assay type: RNA in situ
MGI Accession ID: MGI:5541528
Gene symbol: Dpf3
Gene name: double PHD fingers 3
Probe: RIKEN clone 2810403B03 subclone
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Results
Specimen GUDMAP:12541: embryonic day 15.5 (more )
Note: Labeling was visualized using BM purple.
Structure Level Pattern Image Note
TS23: urinary system Present GUDMAP:12541
TS23: metanephros Present GUDMAP:12541
TS23: nephrogenic zone Present GUDMAP:12541
TS23: cap mesenchyme Present GUDMAP:12541
TS23: s-shaped body Present GUDMAP:12541
TS23: proximal segment of s-shaped body Present GUDMAP:12541
TS23: visceral epithelium of s-shaped body Present GUDMAP:12541
TS23: capillary loop renal corpuscle Present GUDMAP:12541
TS23: visceral epithelium of capillary loop renal corpuscle Present GUDMAP:12541
TS23: maturing renal corpuscle Present GUDMAP:12541
TS23: visceral epithelium of maturing renal corpuscle Present GUDMAP:12541
TS23: nephrogenic interstitium Ambiguous GUDMAP:12541
TS23: pretubular aggregate Absent GUDMAP:12541
TS23: ureteric tip Absent GUDMAP:12541
TS23: ureteric tree terminal branch excluding tip itself Absent GUDMAP:12541
TS23: renal connecting tubule of s-shaped body Absent GUDMAP:12541
TS23: distal segment of s-shaped body Absent GUDMAP:12541
TS23: medial segment of s-shaped body Absent GUDMAP:12541
TS23: parietal epithelium of s-shaped body Absent GUDMAP:12541
TS23: associated interstitium of capillary loop renal corpuscle Absent GUDMAP:12541
TS23: parietal epithelium of capillary loop renal corpuscle Absent GUDMAP:12541
TS23: presumptive endothelium of capillary loop renal corpuscle Absent GUDMAP:12541
TS23: presumptive mesangium of capillary loop renal corpuscle Absent GUDMAP:12541
TS23: glomerular capillary system of maturing glomerular tuft Absent GUDMAP:12541
TS23: glomerular mesangium of maturing glomerular tuft Absent GUDMAP:12541
TS23: glomerular basement membrane of maturing renal corpuscle Absent GUDMAP:12541
TS23: Bowman's capsule of maturing renal corpuscle Absent GUDMAP:12541
TS23: juxtaglomerular arteriole Absent GUDMAP:12541
TS23: cortical renal tubule Absent GUDMAP:12541
TS23: cortical collecting duct Absent GUDMAP:12541
TS23: renal cortical interstitium Absent GUDMAP:12541
TS23: renal cortical vasculature Absent GUDMAP:12541
TS23: renal cortex Present GUDMAP:12541
TS23: maturing glomerular tuft Present GUDMAP:12541
TS23: early tubule Present GUDMAP:12541
TS23: developing capillary loop stage nephron group Present GUDMAP:12541
TS23: maturing nephron Present GUDMAP:12541
TS23: late tubule Present GUDMAP:12541
TS23: early nephron Present GUDMAP:12541
TS23: renal vesicle Ambiguous GUDMAP:12541
TS23: comma-shaped body Ambiguous GUDMAP:12541
TS23: renal pelvis Absent GUDMAP:12541
TS23: renal medulla Absent GUDMAP:12541
TS23: immature loop of Henle Absent GUDMAP:12541
TS23: medullary collecting duct Absent GUDMAP:12541
TS23: renal medullary interstitium Absent GUDMAP:12541
TS23: renal medullary vasculature Absent GUDMAP:12541
TS23: pelvic urothelial lining Absent GUDMAP:12541
TS23: pelvic smooth muscle Absent GUDMAP:12541
TS23: perihilar interstitium Absent GUDMAP:12541
TS23: collecting duct Absent GUDMAP:12541
TS23: ureteric trunk Absent GUDMAP:12541
TS23: renal interstitium Ambiguous GUDMAP:12541
TS23: renal small blood vessel Absent GUDMAP:12541
TS23: renal cortical capillary Absent GUDMAP:12541
TS23: renal medullary arterial system Absent GUDMAP:12541
TS23: renal medullary capillary Absent GUDMAP:12541
TS23: renal medullary venous system Absent GUDMAP:12541
TS23: renal capillary Absent GUDMAP:12541
TS23: ureter Absent GUDMAP:12541
Specimen GUDMAP:12542: embryonic day 15.5 (more )
Note: Labeling was visualized using BM purple.
Structure Level Pattern Image Note
TS23: ureter Absent GUDMAP:12542
TS23: urothelium of ureter Absent GUDMAP:12542
TS23: ureteral mesenchyme Absent GUDMAP:12542
TS23: ureteral vasculature Absent GUDMAP:12542
