Structure |
Level |
Pattern |
Image |
Note |
TS20: gut |
Present |
Regionally restricted |
6A -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: metanephros |
Present |
Regionally restricted |
6A -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: nervous system |
Present |
Regionally restricted |
6A -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: intestine mesenchyme |
Present |
Regionally restricted |
6A -4.3
|
Expression in gut mesenchyme is restricted to posterior regions of the intestine.
|
TS20: central nervous system |
Present |
Regionally restricted |
6A -4.3
|
Transcripts extend far more anteriorly in the CNS, since the boundary of expression lies in the very posterior hindbrain, close to its junction with the spinal cord.
|
TS20: hindbrain |
Present |
Regionally restricted |
6A -4.3
|
Transcripts extend far more anteriorly in the CNS, since the boundary of expression lies in the very posterior hindbrain, close to its junction with the spinal cord.
|
TS20: spinal cord |
Present |
Regionally restricted |
6A -4.3
|
Transcripts extend far more anteriorly in the CNS, since the boundary of expression lies in the very posterior hindbrain, close to its junction with the spinal cord.
|
TS20: dorsal root ganglion |
Present |
Regionally restricted |
6A -4.3
|
Expression extends very anteriorly in the dorsal root ganglia.
|
Structure |
Level |
Pattern |
Image |
Note |
TS20: T10 vertebral cartilage condensation |
Weak |
|
6B -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: L1 vertebral cartilage condensation |
Strong |
Regionally restricted |
6B -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: L2 vertebral cartilage condensation |
Strong |
Regionally restricted |
6B -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: L3 vertebral cartilage condensation |
Strong |
Regionally restricted |
6B -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: L4 vertebral cartilage condensation |
Strong |
Regionally restricted |
6B -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: L5 vertebral cartilage condensation |
Strong |
Regionally restricted |
6B -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: L6 vertebral cartilage condensation |
Strong |
Regionally restricted |
6B -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: S1 vertebral cartilage condensation |
Strong |
Regionally restricted |
6B -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: S2 vertebral cartilage condensation |
Strong |
Regionally restricted |
6B -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: S3 vertebral pre-cartilage condensation |
Strong |
Regionally restricted |
6B -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: S4 vertebral pre-cartilage condensation |
Strong |
Regionally restricted |
6B -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: T11 vertebral cartilage condensation |
Strong |
Regionally restricted |
6B -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: T12 vertebral cartilage condensation |
Strong |
Regionally restricted |
6B -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: T13 vertebral cartilage condensation |
Strong |
Regionally restricted |
6B -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: tail vertebral pre-cartilage condensation |
Strong |
Regionally restricted |
6B -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: C1 vertebral cartilage condensation |
Absent |
|
6B -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: C2 vertebral cartilage condensation |
Absent |
|
6B -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: C3 vertebral cartilage condensation |
Absent |
|
6B -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: C4 vertebral cartilage condensation |
Absent |
|
6B -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: C5 vertebral cartilage condensation |
Absent |
|
6B -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: C6 vertebral cartilage condensation |
Absent |
|
6B -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: C7 vertebral cartilage condensation |
Absent |
|
6B -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: T1 vertebral cartilage condensation |
Absent |
|
6B -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: T2 vertebral cartilage condensation |
Absent |
|
6B -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: T3 vertebral cartilage condensation |
Absent |
|
6B -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: T4 vertebral cartilage condensation |
Absent |
|
6B -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: T5 vertebral cartilage condensation |
Absent |
|
6B -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: T6 vertebral cartilage condensation |
Absent |
|
6B -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: T7 vertebral cartilage condensation |
Absent |
|
6B -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
TS20: T8 vertebral cartilage condensation |
Absent |
|
6B -4.3
|
The Hox-4.3 expression domain is restricted along the anteroposterior axis in some ectoderm (the nervous system) and mesoderm derivatives (e.g. the prevertebrae, gut, or kidney).
|
