Gene Expression Data
Assay Details
Assay
Reference: J:71876 Kawauchi T, et al., Expression of vinexin alpha in the dorsal half of the eye and in the cardiac outflow tract and atrioventricular canal. Mech Dev. 2001 Aug;106(1-2):147-50
Assay type: RNA in situ
MGI Accession ID: MGI:2183832
Gene symbol: Sorbs3
Gene name: sorbin and SH3 domain containing 3
Probe: pVNSK
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Results
Specimen 1A: embryonic day 10.5 (more )
Structure Level Pattern Image Note
TS17: eye Present Regionally restricted 1A
TS17: heart Present 1A
Specimen 2A: embryonic day 10.0 (more )
Structure Level Pattern Image Note
TS16: eye Present 2A
Specimen 2B: embryonic day 12.5 (more )
Structure Level Pattern Image Note
TS20: retina Present Regionally restricted 2B The authors specify expression in the optic cup.
TS20: hindbrain Present Regionally restricted 2B Expression is in a ventral part.
Specimen 2C: embryonic day 10.5 (more )
Structure Level Pattern Image Note
TS17: optic cup outer layer Present Regionally restricted 2C Expression is in the dorsal half.
Specimen 2D,E: embryonic day 10.5 (more )
Structure Level Pattern Image Note
TS17: optic cup outer layer Present Regionally restricted 2E , 2D Exptression is in the dorsal half.
Specimen 2F: embryonic day 12.5 (more )
Structure Level Pattern Image Note
TS20: pons Present Regionally restricted 2F Expression is ventral.
Specimen Not Shown: embryonic day 13.5 (more )
Structure Level Pattern Image Note
TS21: eye Present
TS21: heart Present
Specimen Not Shown: embryonic day 8.5 (more )
Structure Level Pattern Image Note
TS13: heart Weak
Specimen Not Shown: embryonic day 9.5 (more )
Structure Level Pattern Image Note
TS15: heart Moderate Moderate was chosen to indicate that expression is higher than it was at 8.5 dpc.
Specimen 3A: embryonic day 10.5 (more )
Structure Level Pattern Image Note
TS17: outflow tract Strong 3A , 3B
TS17: atrioventricular canal Moderate 3A , 3B
Specimen 3C,D: embryonic day 10.5 (more )
Structure Level Pattern Image Note
TS17: atrioventricular canal Present 3D , 3C Expression is strong in the endothelial cells, but weak in the mesenchymal cells.
TS17: outflow tract Present 3D , 3C Expression is strong in the endothelial cells, but weak in the mesenchymal cells.
Specimen 4A: embryonic day 12.5 (more )
Structure Level Pattern Image Note
TS20: testis Present 4A
TS20: mesonephros Absent 4A
TS20: metanephros Absent 4A
Specimen 4B: embryonic day 12.5 (more )
Structure Level Pattern Image Note
TS20: ovary Present 4B
TS20: mesonephros Absent 4B
TS20: metanephros Absent 4B
