Gene Expression Data
Assay Details
Assay
Reference: J:125993 Cankaya M, et al., An analysis of expression patterns of genes encoding proteins with catalytic activities. BMC Genomics. 2007;8:232
Assay type: RNA in situ
MGI Accession ID: MGI:3769720
Gene symbol: Tpi1
Gene name: triosephosphate isomerase 1
Probe: MH1224 probe 1008
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 15-30 min. before further processing. A dual signal amplification strategy, termed catalyzed reporter deposition (CARD), was used for detection.
Results
Specimen 3A: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS22: neocortex Strong 3A Tpi
TS22: midbrain Strong 3A Tpi
TS22: cerebellum Strong 3A Tpi
TS22: pons Strong 3A Tpi
TS22: medulla oblongata Strong 3A Tpi
TS22: spinal cord Strong 3A Tpi
TS22: cranial ganglion Strong 3A Tpi
TS22: dorsal root ganglion Strong 3A Tpi
TS22: olfactory epithelium Strong 3A Tpi
TS22: intestine Strong 3A Tpi
TS22: salivary gland Strong 3A Tpi
TS22: tongue Moderate 3A Tpi
TS22: stomach Strong 3A Tpi
TS22: liver Strong 3A Tpi
TS22: lung Moderate 3A Tpi
TS22: metanephros Moderate 3A Tpi
TS22: thyroid gland Strong 3A Tpi
TS22: pituitary gland Strong 3A Tpi
TS22: pancreas Strong 3A Tpi
TS22: adrenal gland Moderate 3A Tpi
TS22: heart Strong 3A Tpi
TS22: skeletal muscle Strong 3A Tpi
TS22: cartilage Absent 3A Tpi There is no expression in the axial cartilage.
TS22: skeleton Absent 3A Tpi There is no expression in the long bones.
Specimen MH1224: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS22: embryo Present Non-Uniform MH1224_4D Expression is present throughout the embryo but its strength varies.
TS22: cerebral cortex ventricular layer Present MH1224_4D This is one of the structures with an elevated expression level.
TS22: choroid plexus Present MH1224_4D This is one of the structures with an elevated expression level.
TS22: cranial ganglion Present MH1224_4D This is one of the structures with an elevated expression level.
TS22: heart Present MH1224_4D This is one of the structures with an elevated expression level.
TS22: lens Present MH1224_4D This is one of the structures with an elevated expression level.
TS22: liver Present MH1224_4D This is one of the structures with an elevated expression level.
TS22: medulla oblongata Present MH1224_4D This is one of the structures with an elevated expression level.
TS22: midbrain Present MH1224_4D This is one of the structures with an elevated expression level.
TS22: pons Present MH1224_4D This is one of the structures with an elevated expression level.
TS22: telencephalon Present Regionally restricted MH1224_4D There are scattered expressing cells located at the striatal-cortical interface.
TS22: spinal cord Present Non-Uniform MH1224_4D Expression is present in the spinal cord, most strongly in the motor column.
TS22: cerebellum Present MH1224_4D
TS22: intervertebral disc Present MH1224_4D
TS22: limb joint primordium Present MH1224_4D
TS22: lung Present MH1224_4D
TS22: peripheral nervous system Present MH1224_4D
TS22: piriform cortex Present MH1224_4D
TS22: pituitary gland Present MH1224_4D
TS22: retina Present MH1224_4D
TS22: skeletal muscle Present MH1224_4D
TS22: epidermis Present MH1224_4D Expression is present in the epidermis. This includes the facial epithelium.
