Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4824254
Gene symbol: Dct
Gene name: dopachrome tautomerase
Probe: MGC clone 91377
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen S6 C/D - Dct: embryonic day 14.5 (more )
Note: This specimen is a merged color composite; it was assumed this image was derived from specimens in this assay. Its annotations were inferred by a GXD curator using the structure key presented in the figure legend.
Structure Level Pattern Image Note
TS23: telencephalon Present Regionally restricted S6D Expression is present in the lateral and dorsal pallium.
Specimen S6 E/F - Dct: embryonic day 14.5 (more )
Note: This specimen is a merged color composite; it was assumed this image was derived from specimens in this assay. Its annotations were inferred by a GXD curator using the structure key presented in the figure legend.
Structure Level Pattern Image Note
TS23: telencephalon Present Regionally restricted S6F Expression is present in the lateral pallium.
Specimen euxassay_005958_01: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Weak Regionally restricted euxassay_005958_01
TS23: fibula Weak Regionally restricted euxassay_005958_01
TS23: tibia Weak Regionally restricted euxassay_005958_01
TS23: humerus Weak Regionally restricted euxassay_005958_01
TS23: scapula Weak Regionally restricted euxassay_005958_01
TS23: exoccipital bone Weak Regionally restricted euxassay_005958_01
TS23: orbito-sphenoid Weak Regionally restricted euxassay_005958_01
TS23: temporal bone Weak Regionally restricted euxassay_005958_01
Specimen euxassay_005958_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Weak Regionally restricted euxassay_005958_02
TS23: femur Weak Regionally restricted euxassay_005958_02
TS23: humerus Weak Regionally restricted euxassay_005958_02
TS23: scapula Weak Regionally restricted euxassay_005958_02
TS23: temporal bone Weak Regionally restricted euxassay_005958_02
TS23: exoccipital bone Weak Regionally restricted euxassay_005958_02
Specimen euxassay_005958_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Weak Regionally restricted euxassay_005958_03
TS23: femur Weak Regionally restricted euxassay_005958_03
TS23: humerus Weak Regionally restricted euxassay_005958_03
TS23: exoccipital bone Weak Regionally restricted euxassay_005958_03
TS23: temporal bone Weak Regionally restricted euxassay_005958_03
Specimen euxassay_005958_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Weak Regionally restricted euxassay_005958_04
TS23: femur Weak Regionally restricted euxassay_005958_04
TS23: extrinsic ocular muscle Strong Spotted euxassay_005958_04
Specimen euxassay_005958_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Weak Regionally restricted euxassay_005958_05
TS23: extrinsic ocular muscle Strong Spotted euxassay_005958_05
TS23: vibrissa Strong Regionally restricted euxassay_005958_05
TS23: orbito-sphenoid Weak Regionally restricted euxassay_005958_05
Specimen euxassay_005958_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Weak Regionally restricted euxassay_005958_06
TS23: axial skeleton Weak Regionally restricted euxassay_005958_06
TS23: pelvic girdle skeleton Weak Regionally restricted euxassay_005958_06
TS23: extrinsic ocular muscle Strong Spotted euxassay_005958_06
TS23: vibrissa Strong Regionally restricted euxassay_005958_06
TS23: orbito-sphenoid Weak Regionally restricted euxassay_005958_06
Specimen euxassay_005958_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: axial skeleton Weak Regionally restricted euxassay_005958_07
TS23: pelvic girdle skeleton Weak Regionally restricted euxassay_005958_07
TS23: extrinsic ocular muscle Strong Spotted euxassay_005958_07
TS23: vibrissa Strong Regionally restricted euxassay_005958_07
TS23: orbito-sphenoid Weak Regionally restricted euxassay_005958_07
Specimen euxassay_005958_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: axial skeleton Weak Regionally restricted euxassay_005958_08
TS23: rib Weak Regionally restricted euxassay_005958_08
TS23: pelvic girdle skeleton Weak Regionally restricted euxassay_005958_08
TS23: vibrissa Strong Regionally restricted euxassay_005958_08
TS23: orbito-sphenoid Weak Regionally restricted euxassay_005958_08
TS23: turbinate bone primordium Weak Regionally restricted euxassay_005958_08
TS23: basioccipital bone Weak Regionally restricted euxassay_005958_08
TS23: basisphenoid bone Weak Regionally restricted euxassay_005958_08
Specimen euxassay_005958_09: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: axial skeleton Weak Regionally restricted euxassay_005958_09
TS23: heart valve Strong Regionally restricted euxassay_005958_09
TS23: turbinate bone primordium Weak Regionally restricted euxassay_005958_09
Specimen euxassay_005958_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: axial skeleton Weak Regionally restricted euxassay_005958_10
TS23: heart valve Strong Regionally restricted euxassay_005958_10
TS23: turbinate bone primordium Weak Regionally restricted euxassay_005958_10
TS23: basisphenoid bone Weak Regionally restricted euxassay_005958_10
TS23: basioccipital bone Weak Regionally restricted euxassay_005958_10
Specimen euxassay_005958_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: axial skeleton Weak Regionally restricted euxassay_005958_11
TS23: telencephalon ventricular layer Strong Regionally restricted euxassay_005958_11
TS23: heart valve Strong Regionally restricted euxassay_005958_11
Specimen euxassay_005958_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: axial skeleton Weak Regionally restricted euxassay_005958_12
TS23: telencephalon ventricular layer Strong Regionally restricted euxassay_005958_12
TS23: heart valve Strong Regionally restricted euxassay_005958_12
TS23: basisphenoid bone Weak Regionally restricted euxassay_005958_12
TS23: basioccipital bone Weak Regionally restricted euxassay_005958_12
Specimen euxassay_005958_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: axial skeleton Weak Regionally restricted euxassay_005958_13
TS23: rib Weak Regionally restricted euxassay_005958_13
TS23: pelvic girdle skeleton Weak Regionally restricted euxassay_005958_13
TS23: telencephalon ventricular layer Strong Regionally restricted euxassay_005958_13
TS23: basisphenoid bone Weak Regionally restricted euxassay_005958_13
TS23: basioccipital bone Weak Regionally restricted euxassay_005958_13
Specimen euxassay_005958_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: axial skeleton Weak Regionally restricted euxassay_005958_14
TS23: pelvic girdle skeleton Weak Regionally restricted euxassay_005958_14
Specimen euxassay_005958_15: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Weak Regionally restricted euxassay_005958_15
TS23: telencephalon ventricular layer Strong Regionally restricted euxassay_005958_15
Specimen euxassay_005958_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Weak Regionally restricted euxassay_005958_16
TS23: telencephalon ventricular layer Strong Regionally restricted euxassay_005958_16
TS23: exoccipital bone Weak Regionally restricted euxassay_005958_16
Specimen euxassay_005958_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Weak Regionally restricted euxassay_005958_17
TS23: femur Weak Regionally restricted euxassay_005958_17
TS23: telencephalon ventricular layer Strong Regionally restricted euxassay_005958_17
TS23: turbinate bone primordium Weak Regionally restricted euxassay_005958_17
Specimen euxassay_005958_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Weak Regionally restricted euxassay_005958_18
TS23: femur Weak Regionally restricted euxassay_005958_18
TS23: telencephalon ventricular layer Strong Regionally restricted euxassay_005958_18
TS23: humerus Weak Regionally restricted euxassay_005958_18
TS23: scapula Weak Regionally restricted euxassay_005958_18
TS23: orbito-sphenoid Weak Regionally restricted euxassay_005958_18
TS23: turbinate bone primordium Weak Regionally restricted euxassay_005958_18
TS23: temporal bone Weak Regionally restricted euxassay_005958_18
Specimen euxassay_005958_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Weak Regionally restricted euxassay_005958_19
TS23: femur Weak Regionally restricted euxassay_005958_19
TS23: extrinsic ocular muscle Strong Spotted euxassay_005958_19
TS23: humerus Weak Regionally restricted euxassay_005958_19
TS23: scapula Weak Regionally restricted euxassay_005958_19
TS23: orbito-sphenoid Weak Regionally restricted euxassay_005958_19
TS23: turbinate bone primordium Weak Regionally restricted euxassay_005958_19
TS23: temporal bone Weak Regionally restricted euxassay_005958_19
Specimen euxassay_005958_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Weak Regionally restricted euxassay_005958_20
TS23: femur Weak Regionally restricted euxassay_005958_20
TS23: extrinsic ocular muscle Strong Spotted euxassay_005958_20
TS23: vibrissa Strong Regionally restricted euxassay_005958_20
TS23: humerus Weak Regionally restricted euxassay_005958_20
TS23: orbito-sphenoid Weak Regionally restricted euxassay_005958_20
TS23: temporal bone Weak Regionally restricted euxassay_005958_20
Specimen euxassay_005958_21: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Weak Regionally restricted euxassay_005958_21
TS23: femur Weak Regionally restricted euxassay_005958_21
TS23: extrinsic ocular muscle Strong Spotted euxassay_005958_21
TS23: vibrissa Strong Regionally restricted euxassay_005958_21
TS23: humerus Weak Regionally restricted euxassay_005958_21
TS23: temporal bone Weak Regionally restricted euxassay_005958_21
Specimen euxassay_005958_22: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Weak Regionally restricted euxassay_005958_22
TS23: femur Weak Regionally restricted euxassay_005958_22
TS23: tibia Weak Regionally restricted euxassay_005958_22
TS23: fibula Weak Regionally restricted euxassay_005958_22
TS23: vibrissa Strong Regionally restricted euxassay_005958_22
TS23: humerus Moderate Regionally restricted euxassay_005958_22
