Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4825777
Gene symbol: Kirrel1
Gene name: kirre like nephrin family adhesion molecule 1
Probe: T31558
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_012636_01: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: orbito-sphenoid Moderate Regionally restricted euxassay_012636_01
Specimen euxassay_012636_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: orbito-sphenoid Moderate Regionally restricted euxassay_012636_02
Specimen euxassay_012636_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: orbito-sphenoid Moderate Regionally restricted euxassay_012636_03
TS23: maxilla Weak Regionally restricted euxassay_012636_03
TS23: mandible Weak Regionally restricted euxassay_012636_03
Specimen euxassay_012636_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: orbito-sphenoid Weak Regionally restricted euxassay_012636_04
TS23: maxilla Weak Regionally restricted euxassay_012636_04
TS23: mandible Weak Regionally restricted euxassay_012636_04
TS23: lung Weak Spotted euxassay_012636_04
Specimen euxassay_012636_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: maxilla Weak Regionally restricted euxassay_012636_05
TS23: mandible Weak Regionally restricted euxassay_012636_05
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_012636_05
TS23: pons mantle layer Weak Regionally restricted euxassay_012636_05
TS23: lung Weak Spotted euxassay_012636_05
Specimen euxassay_012636_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: mandible Weak Regionally restricted euxassay_012636_06
TS23: maxilla Weak Regionally restricted euxassay_012636_06
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_012636_06
TS23: pons mantle layer Weak Regionally restricted euxassay_012636_06
TS23: medulla oblongata basal plate mantle layer Weak Regionally restricted euxassay_012636_06
TS23: turbinate bone primordium Weak Regionally restricted euxassay_012636_06
TS23: lung Weak Spotted euxassay_012636_06
Specimen euxassay_012636_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: mandible Weak Regionally restricted euxassay_012636_07
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_012636_07
TS23: diencephalon lateral wall mantle layer Moderate Regionally restricted euxassay_012636_07
TS23: pons mantle layer Weak Regionally restricted euxassay_012636_07
TS23: medulla oblongata basal plate mantle layer Weak Regionally restricted euxassay_012636_07
TS23: dorsal grey horn Weak Regionally restricted euxassay_012636_07
TS23: turbinate bone primordium Weak Regionally restricted euxassay_012636_07
TS23: lung Weak Spotted euxassay_012636_07
Specimen euxassay_012636_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diencephalon lateral wall mantle layer Moderate Regionally restricted euxassay_012636_08
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_012636_08
TS23: pons mantle layer Weak Regionally restricted euxassay_012636_08
TS23: medulla oblongata basal plate mantle layer Weak Regionally restricted euxassay_012636_08
TS23: dorsal grey horn Weak Regionally restricted euxassay_012636_08
TS23: turbinate bone primordium Weak Regionally restricted euxassay_012636_08
TS23: lung Weak Spotted euxassay_012636_08
Specimen euxassay_012636_09: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_012636_09
TS23: diencephalon lateral wall mantle layer Moderate Regionally restricted euxassay_012636_09
TS23: pons mantle layer Weak Regionally restricted euxassay_012636_09
TS23: medulla oblongata basal plate mantle layer Weak Regionally restricted euxassay_012636_09
TS23: dorsal grey horn Weak Regionally restricted euxassay_012636_09
TS23: nasal septum Weak Regionally restricted euxassay_012636_09
TS23: lung Weak Spotted euxassay_012636_09
Specimen euxassay_012636_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_012636_10
TS23: diencephalon lateral wall mantle layer Moderate Regionally restricted euxassay_012636_10
TS23: pons mantle layer Weak Regionally restricted euxassay_012636_10
TS23: medulla oblongata basal plate mantle layer Weak Regionally restricted euxassay_012636_10
TS23: dorsal grey horn Weak Regionally restricted euxassay_012636_10
TS23: lung Weak Spotted euxassay_012636_10
Specimen euxassay_012636_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: dorsal grey horn Weak Regionally restricted euxassay_012636_11
TS23: nasal septum Weak Regionally restricted euxassay_012636_11
Specimen euxassay_012636_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: mandible Weak Regionally restricted euxassay_012636_12
TS23: dorsal grey horn Weak Regionally restricted euxassay_012636_12
TS23: nasal septum Weak Regionally restricted euxassay_012636_12
Specimen euxassay_012636_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_012636_13
TS23: diencephalon lateral wall mantle layer Moderate Regionally restricted euxassay_012636_13
TS23: dorsal grey horn Weak Regionally restricted euxassay_012636_13
TS23: turbinate bone primordium Weak Regionally restricted euxassay_012636_13
TS23: lung Weak Spotted euxassay_012636_13
Specimen euxassay_012636_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: mandible Weak Regionally restricted euxassay_012636_14
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_012636_14
TS23: diencephalon lateral wall mantle layer Moderate Regionally restricted euxassay_012636_14
TS23: dorsal grey horn Weak Regionally restricted euxassay_012636_14
TS23: turbinate bone primordium Weak Regionally restricted euxassay_012636_14
TS23: lung Weak Spotted euxassay_012636_14
Specimen euxassay_012636_15: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: maxilla Weak Regionally restricted euxassay_012636_15
TS23: mandible Weak Regionally restricted euxassay_012636_15
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_012636_15
TS23: diencephalon lateral wall mantle layer Moderate Regionally restricted euxassay_012636_15
TS23: medulla oblongata basal plate mantle layer Weak Regionally restricted euxassay_012636_15
TS23: pons mantle layer Weak Regionally restricted euxassay_012636_15
TS23: dorsal grey horn Weak Regionally restricted euxassay_012636_15
TS23: turbinate bone primordium Weak Regionally restricted euxassay_012636_15
TS23: lung Weak Spotted euxassay_012636_15
Specimen euxassay_012636_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: maxilla Weak Regionally restricted euxassay_012636_16
TS23: mandible Weak Regionally restricted euxassay_012636_16
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_012636_16
TS23: diencephalon lateral wall mantle layer Moderate Regionally restricted euxassay_012636_16
TS23: pons mantle layer Moderate Regionally restricted euxassay_012636_16
TS23: medulla oblongata basal plate mantle layer Moderate Regionally restricted euxassay_012636_16
TS23: lung Weak Spotted euxassay_012636_16
Specimen euxassay_012636_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: maxilla Weak Regionally restricted euxassay_012636_17
TS23: mandible Weak Regionally restricted euxassay_012636_17
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_012636_17
TS23: pons mantle layer Moderate Regionally restricted euxassay_012636_17
TS23: lung Weak Spotted euxassay_012636_17
Specimen euxassay_012636_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: mandible Weak Regionally restricted euxassay_012636_18
TS23: maxilla Weak Regionally restricted euxassay_012636_18
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_012636_18
TS23: lung Weak Spotted euxassay_012636_18
Specimen euxassay_012636_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: orbito-sphenoid Weak Regionally restricted euxassay_012636_19
TS23: lung Weak Spotted euxassay_012636_19
Specimen euxassay_012636_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: orbito-sphenoid Weak Regionally restricted euxassay_012636_20
TS23: lung Weak Spotted euxassay_012636_20
