Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4825958
Gene symbol: Lnx2
Gene name: ligand of numb-protein X 2
Probe: T37784
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen S6 C/D - Lnx: embryonic day 14.5 (more )
Note: This specimen is a merged color composite; it was assumed this image was derived from specimens in this assay. Its annotations were inferred by a GXD curator using the structure key presented in the figure legend.
Structure Level Pattern Image Note
TS23: medial ganglionic eminence Present S6D
Specimen S6 E/F - Lnx: embryonic day 14.5 (more )
Note: This specimen is a merged color composite; it was assumed this image was derived from specimens in this assay. Its annotations were inferred by a GXD curator using the structure key presented in the figure legend.
Structure Level Pattern Image Note
TS23: medial ganglionic eminence Present S6F
Specimen Table S5 - Lnx2: embryonic day 14.5 (more )
Note: The probe used to generate this data was not specified; another gene-specific probe may have been used.
Structure Level Pattern Image Note
TS23: cerebral cortex Moderate
Specimen euxassay_013699_01: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013699_01
Specimen euxassay_013699_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013699_02
Specimen euxassay_013699_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013699_03
Specimen euxassay_013699_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013699_04
Specimen euxassay_013699_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex marginal layer Moderate Regionally restricted euxassay_013699_05
Specimen euxassay_013699_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex marginal layer Moderate Regionally restricted euxassay_013699_06
Specimen euxassay_013699_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex marginal layer Moderate Regionally restricted euxassay_013699_07
Specimen euxassay_013699_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013699_08
Specimen euxassay_013699_09: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013699_09
Specimen euxassay_013699_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013699_10
Specimen euxassay_013699_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013699_11
Specimen euxassay_013699_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013699_12
Specimen euxassay_013699_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013699_14
Specimen euxassay_013699_15: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013699_15
Specimen euxassay_013699_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013699_16
Specimen euxassay_013699_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013699_17
Specimen euxassay_013699_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013699_18
Specimen euxassay_013699_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex marginal layer Moderate Regionally restricted euxassay_013699_19
Specimen euxassay_013699_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex marginal layer Moderate Regionally restricted euxassay_013699_20
Specimen euxassay_013699_21: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex marginal layer Moderate Regionally restricted euxassay_013699_21
Specimen euxassay_013699_22: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013699_22
Specimen euxassay_013699_23: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013699_23
Specimen euxassay_013699_24: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013699_24
