Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4826817
Gene symbol: Ntn1
Gene name: netrin 1
Probe: T36707
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen S6 A/B - Ntn1: embryonic day 14.5 (more )
Note: This specimen is a merged color composite; it was assumed this image was derived from specimens in this assay. Its annotations were inferred by a GXD curator using the structure key presented in the figure legend.
Structure Level Pattern Image Note
TS23: lateral ventricle choroid plexus Present S6B
TS23: telencephalon septum Present S6B
TS23: thalamus Present S6B
Specimen euxassay_007630_01: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: anterior abdominal wall muscle Weak Regionally restricted euxassay_007630_01
Specimen euxassay_007630_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: extrinsic ocular muscle Moderate Regionally restricted euxassay_007630_02
TS23: vibrissa Weak Regionally restricted euxassay_007630_02
TS23: stomach Moderate Regionally restricted euxassay_007630_02
TS23: anterior abdominal wall muscle Weak Regionally restricted euxassay_007630_02
TS23: axial muscle Weak Regionally restricted euxassay_007630_02
Specimen euxassay_007630_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: extrinsic ocular muscle Moderate Regionally restricted euxassay_007630_03
TS23: vibrissa Weak Regionally restricted euxassay_007630_03
TS23: stomach Moderate Regionally restricted euxassay_007630_03
TS23: lung Weak Regionally restricted euxassay_007630_03
TS23: saccule Weak Regionally restricted euxassay_007630_03
TS23: axial muscle Weak Regionally restricted euxassay_007630_03
TS23: anterior abdominal wall muscle Weak Regionally restricted euxassay_007630_03
Specimen euxassay_007630_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: extrinsic ocular muscle Weak Regionally restricted euxassay_007630_04
TS23: vibrissa Weak Regionally restricted euxassay_007630_04
TS23: stomach Moderate Regionally restricted euxassay_007630_04
TS23: midgut Weak Regionally restricted euxassay_007630_04
TS23: lung Weak Regionally restricted euxassay_007630_04
TS23: saccule Weak Regionally restricted euxassay_007630_04
TS23: telencephalon mantle layer Moderate Regionally restricted euxassay_007630_04
Specimen euxassay_007630_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: midgut Weak Regionally restricted euxassay_007630_05
TS23: stomach Moderate Regionally restricted euxassay_007630_05
TS23: lung Weak Regionally restricted euxassay_007630_05
TS23: saccule Weak Regionally restricted euxassay_007630_05
TS23: anterior abdominal wall muscle Weak Regionally restricted euxassay_007630_05
TS23: telencephalon ventricular layer Weak Regionally restricted euxassay_007630_05
Specimen euxassay_007630_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: stomach Moderate Regionally restricted euxassay_007630_06
TS23: olfactory epithelium Weak Regionally restricted euxassay_007630_06
TS23: lung Weak Regionally restricted euxassay_007630_06
TS23: heart ventricle Weak Regionally restricted euxassay_007630_06
TS23: anterior abdominal wall muscle Weak Regionally restricted euxassay_007630_06
TS23: telencephalon ventricular layer Weak Regionally restricted euxassay_007630_06
TS23: telencephalon mantle layer Moderate Regionally restricted euxassay_007630_06
Specimen euxassay_007630_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: stomach Moderate Regionally restricted euxassay_007630_07
TS23: midgut Moderate Regionally restricted euxassay_007630_07
TS23: olfactory epithelium Moderate Regionally restricted euxassay_007630_07
TS23: lung Weak Regionally restricted euxassay_007630_07
TS23: heart ventricle Weak Regionally restricted euxassay_007630_07
TS23: renal cortex Strong Regionally restricted euxassay_007630_07
TS23: saccule Weak Regionally restricted euxassay_007630_07
TS23: telencephalon ventricular layer Moderate Regionally restricted euxassay_007630_07
TS23: telencephalon mantle layer Moderate Regionally restricted euxassay_007630_07
Specimen euxassay_007630_08: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: midgut Moderate Regionally restricted euxassay_007630_08
TS23: stomach Moderate Regionally restricted euxassay_007630_08
TS23: olfactory epithelium Moderate Regionally restricted euxassay_007630_08
TS23: lung Weak Regionally restricted euxassay_007630_08
TS23: heart ventricle Weak Regionally restricted euxassay_007630_08
TS23: renal cortex Strong Regionally restricted euxassay_007630_08
TS23: saccule Weak Regionally restricted euxassay_007630_08
TS23: telencephalon ventricular layer Moderate Regionally restricted euxassay_007630_08
TS23: pons ventricular layer Strong Regionally restricted euxassay_007630_08
TS23: midbrain mantle layer Strong Single cells euxassay_007630_08
TS23: midbrain-hindbrain junction Present euxassay_007630_08
Specimen euxassay_007630_09: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: midgut Moderate Regionally restricted euxassay_007630_09
TS23: stomach Weak Regionally restricted euxassay_007630_09
TS23: olfactory epithelium Moderate Regionally restricted euxassay_007630_09
TS23: lung Weak Regionally restricted euxassay_007630_09
TS23: heart ventricle Weak Regionally restricted euxassay_007630_09
TS23: renal cortex Strong Regionally restricted euxassay_007630_09
TS23: telencephalon ventricular layer Moderate Regionally restricted euxassay_007630_09
TS23: telencephalon mantle layer Moderate Regionally restricted euxassay_007630_09
TS23: pons ventricular layer Strong Regionally restricted euxassay_007630_09
TS23: midbrain mantle layer Strong Single cells euxassay_007630_09
TS23: midbrain-hindbrain junction Present euxassay_007630_09
Specimen euxassay_007630_10: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: midgut Moderate Regionally restricted euxassay_007630_10
TS23: olfactory epithelium Moderate Regionally restricted euxassay_007630_10
TS23: lung Weak Regionally restricted euxassay_007630_10
TS23: heart ventricle Weak Regionally restricted euxassay_007630_10
TS23: renal cortex Strong Regionally restricted euxassay_007630_10
TS23: telencephalon ventricular layer Moderate Regionally restricted euxassay_007630_10
TS23: telencephalon mantle layer Moderate Regionally restricted euxassay_007630_10
TS23: pons ventricular layer Strong Regionally restricted euxassay_007630_10
TS23: midbrain ventricular layer Strong Regionally restricted euxassay_007630_10
TS23: midbrain mantle layer Strong Single cells euxassay_007630_10
TS23: midbrain-hindbrain junction Present euxassay_007630_10
TS23: diencephalon lateral wall ventricular layer Weak Regionally restricted euxassay_007630_10
TS23: hypothalamus ventricular layer Weak Regionally restricted euxassay_007630_10
TS23: dorsal grey horn Strong Single cells euxassay_007630_10
Specimen euxassay_007630_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: midgut Moderate Regionally restricted euxassay_007630_11
TS23: olfactory epithelium Moderate Regionally restricted euxassay_007630_11
TS23: lung Weak Regionally restricted euxassay_007630_11
TS23: heart ventricle Weak Regionally restricted euxassay_007630_11
TS23: tongue Strong Regionally restricted euxassay_007630_11
TS23: axial skeleton tail region Strong Regionally restricted euxassay_007630_11
TS23: telencephalon ventricular layer Moderate Regionally restricted euxassay_007630_11
TS23: telencephalon mantle layer Moderate Regionally restricted euxassay_007630_11
TS23: pons ventricular layer Strong Regionally restricted euxassay_007630_11
TS23: midbrain ventricular layer Strong Regionally restricted euxassay_007630_11
TS23: diencephalon lateral wall ventricular layer Moderate Regionally restricted euxassay_007630_11
TS23: hypothalamus ventricular layer Moderate Regionally restricted euxassay_007630_11
TS23: ventral grey horn Strong Single cells euxassay_007630_11
TS23: dorsal grey horn Strong Single cells euxassay_007630_11
Specimen euxassay_007630_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: midgut Moderate Regionally restricted euxassay_007630_12
TS23: olfactory epithelium Moderate Regionally restricted euxassay_007630_12
TS23: heart ventricle Weak Regionally restricted euxassay_007630_12
TS23: esophagus Moderate Regionally restricted euxassay_007630_12
TS23: tongue Strong Regionally restricted euxassay_007630_12
TS23: axial skeleton tail region Strong Regionally restricted euxassay_007630_12
TS23: axial skeleton Strong Regionally restricted euxassay_007630_12
TS23: telencephalon ventricular layer Strong Regionally restricted euxassay_007630_12
TS23: midbrain ventricular layer Strong Regionally restricted euxassay_007630_12
TS23: pons ventricular layer Strong Regionally restricted euxassay_007630_12
TS23: diencephalon lateral wall ventricular layer Strong Regionally restricted euxassay_007630_12
TS23: hypothalamus ventricular layer Strong Regionally restricted euxassay_007630_12
TS23: spinal cord ventricular layer Strong Single cells euxassay_007630_12
TS23: ventral grey horn Strong Single cells euxassay_007630_12
TS23: dorsal grey horn Strong Single cells euxassay_007630_12
Specimen euxassay_007630_13: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: midgut Moderate Regionally restricted euxassay_007630_13
TS23: hindgut Moderate Regionally restricted euxassay_007630_13
TS23: olfactory epithelium Moderate Regionally restricted euxassay_007630_13
TS23: heart ventricle Weak Regionally restricted euxassay_007630_13
TS23: esophagus Moderate Regionally restricted euxassay_007630_13
TS23: tongue Strong Regionally restricted euxassay_007630_13
TS23: axial skeleton tail region Strong Regionally restricted euxassay_007630_13
TS23: axial skeleton Strong Regionally restricted euxassay_007630_13
TS23: telencephalon ventricular layer Strong Regionally restricted euxassay_007630_13
TS23: midbrain ventricular layer Strong Regionally restricted euxassay_007630_13
TS23: pons ventricular layer Strong Regionally restricted euxassay_007630_13
TS23: medulla oblongata basal plate ventricular layer Strong Regionally restricted euxassay_007630_13
TS23: midbrain mantle layer Strong Single cells euxassay_007630_13
TS23: midbrain-hindbrain junction Present euxassay_007630_13
TS23: diencephalon lateral wall ventricular layer Strong Regionally restricted euxassay_007630_13
TS23: hypothalamus ventricular layer Strong Regionally restricted euxassay_007630_13
TS23: ventral grey horn Strong Single cells euxassay_007630_13
TS23: dorsal grey horn Strong Single cells euxassay_007630_13
TS23: spinal cord ventricular layer Strong Single cells euxassay_007630_13
Specimen euxassay_007630_14: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: midgut Moderate Regionally restricted euxassay_007630_14
TS23: hindgut Moderate Regionally restricted euxassay_007630_14
TS23: olfactory epithelium Moderate Regionally restricted euxassay_007630_14
TS23: lung Moderate Regionally restricted euxassay_007630_14
TS23: heart ventricle Weak Regionally restricted euxassay_007630_14
TS23: tongue Moderate Regionally restricted euxassay_007630_14
TS23: axial skeleton tail region Strong Regionally restricted euxassay_007630_14
TS23: axial skeleton Strong Regionally restricted euxassay_007630_14
TS23: telencephalon ventricular layer Strong Regionally restricted euxassay_007630_14
TS23: pons ventricular layer Strong Regionally restricted euxassay_007630_14
TS23: midbrain ventricular layer Strong Regionally restricted euxassay_007630_14
TS23: medulla oblongata basal plate ventricular layer Strong Regionally restricted euxassay_007630_14
TS23: midbrain mantle layer Strong Single cells euxassay_007630_14
TS23: midbrain-hindbrain junction Present euxassay_007630_14
TS23: diencephalon lateral wall ventricular layer Strong Regionally restricted euxassay_007630_14
TS23: hypothalamus ventricular layer Strong Regionally restricted euxassay_007630_14
TS23: ventral grey horn Strong Single cells euxassay_007630_14
TS23: dorsal grey horn Strong Single cells euxassay_007630_14
TS23: spinal cord ventricular layer Strong Single cells euxassay_007630_14
Specimen euxassay_007630_15: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: hindgut Moderate Regionally restricted euxassay_007630_15
TS23: midgut Moderate Regionally restricted euxassay_007630_15
TS23: olfactory epithelium Moderate Regionally restricted euxassay_007630_15
TS23: lung Moderate Regionally restricted euxassay_007630_15
TS23: renal cortex Strong Regionally restricted euxassay_007630_15
TS23: axial skeleton tail region Strong Regionally restricted euxassay_007630_15
TS23: telencephalon ventricular layer Strong Regionally restricted euxassay_007630_15
TS23: midbrain ventricular layer Strong Regionally restricted euxassay_007630_15
TS23: pons ventricular layer Strong Regionally restricted euxassay_007630_15
TS23: medulla oblongata basal plate ventricular layer Strong Regionally restricted euxassay_007630_15
TS23: midbrain mantle layer Strong Single cells euxassay_007630_15
TS23: midbrain-hindbrain junction Present euxassay_007630_15
TS23: diencephalon lateral wall ventricular layer Moderate Regionally restricted euxassay_007630_15
TS23: hypothalamus ventricular layer Moderate Regionally restricted euxassay_007630_15
TS23: dorsal grey horn Strong Single cells euxassay_007630_15
TS23: ventral grey horn Strong Single cells euxassay_007630_15
Specimen euxassay_007630_16: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: midgut Moderate Regionally restricted euxassay_007630_16
TS23: olfactory epithelium Weak Regionally restricted euxassay_007630_16
TS23: lung Moderate Regionally restricted euxassay_007630_16
TS23: renal cortex Strong Regionally restricted euxassay_007630_16
TS23: telencephalon ventricular layer Strong Regionally restricted euxassay_007630_16
TS23: telencephalon mantle layer Strong Regionally restricted euxassay_007630_16
TS23: midbrain ventricular layer Strong Regionally restricted euxassay_007630_16
TS23: pons ventricular layer Strong Regionally restricted euxassay_007630_16
TS23: medulla oblongata basal plate ventricular layer Strong Regionally restricted euxassay_007630_16
TS23: midbrain mantle layer Strong Single cells euxassay_007630_16
TS23: midbrain-hindbrain junction Present euxassay_007630_16
TS23: dorsal grey horn Moderate Single cells euxassay_007630_16
TS23: ventral grey horn Moderate Single cells euxassay_007630_16
Specimen euxassay_007630_17: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: midgut Weak Regionally restricted euxassay_007630_17
TS23: lung Moderate Regionally restricted euxassay_007630_17
TS23: renal cortex Strong Regionally restricted euxassay_007630_17
TS23: saccule Weak Regionally restricted euxassay_007630_17
TS23: telencephalon ventricular layer Moderate Regionally restricted euxassay_007630_17
TS23: telencephalon mantle layer Moderate Regionally restricted euxassay_007630_17
TS23: medulla oblongata basal plate ventricular layer Strong Regionally restricted euxassay_007630_17
TS23: pons ventricular layer Strong Regionally restricted euxassay_007630_17
TS23: midbrain ventricular layer Strong Regionally restricted euxassay_007630_17
TS23: midbrain mantle layer Strong Single cells euxassay_007630_17
TS23: midbrain-hindbrain junction Present euxassay_007630_17
TS23: dorsal grey horn Moderate Single cells euxassay_007630_17
Specimen euxassay_007630_18: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: vibrissa Weak Regionally restricted euxassay_007630_18
TS23: midgut Weak Regionally restricted euxassay_007630_18
TS23: lung Moderate Regionally restricted euxassay_007630_18
TS23: renal cortex Strong Regionally restricted euxassay_007630_18
TS23: saccule Weak Regionally restricted euxassay_007630_18
TS23: anterior abdominal wall muscle Weak Regionally restricted euxassay_007630_18
TS23: telencephalon mantle layer Moderate Regionally restricted euxassay_007630_18
TS23: telencephalon ventricular layer Moderate Regionally restricted euxassay_007630_18
TS23: midbrain ventricular layer Strong Regionally restricted euxassay_007630_18
TS23: pons ventricular layer Strong Regionally restricted euxassay_007630_18
TS23: medulla oblongata basal plate ventricular layer Strong Regionally restricted euxassay_007630_18
TS23: midbrain mantle layer Strong Single cells euxassay_007630_18
TS23: midbrain-hindbrain junction Present euxassay_007630_18
Specimen euxassay_007630_19: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: vibrissa Weak Regionally restricted euxassay_007630_19
TS23: lung Moderate Regionally restricted euxassay_007630_19
TS23: renal cortex Strong Regionally restricted euxassay_007630_19
TS23: saccule Moderate Regionally restricted euxassay_007630_19
TS23: anterior abdominal wall muscle Weak Regionally restricted euxassay_007630_19
TS23: telencephalon mantle layer Moderate Regionally restricted euxassay_007630_19
TS23: telencephalon ventricular layer Moderate Regionally restricted euxassay_007630_19
TS23: midbrain ventricular layer Strong Regionally restricted euxassay_007630_19
TS23: pons ventricular layer Strong Regionally restricted euxassay_007630_19
TS23: medulla oblongata basal plate ventricular layer Strong Regionally restricted euxassay_007630_19
TS23: midbrain mantle layer Strong Single cells euxassay_007630_19
TS23: midbrain-hindbrain junction Present euxassay_007630_19
Specimen euxassay_007630_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: extrinsic ocular muscle Moderate Regionally restricted euxassay_007630_20
TS23: lung Moderate Regionally restricted euxassay_007630_20
TS23: saccule Moderate Regionally restricted euxassay_007630_20
TS23: anterior abdominal wall muscle Weak Regionally restricted euxassay_007630_20
TS23: telencephalon mantle layer Moderate Regionally restricted euxassay_007630_20
TS23: telencephalon ventricular layer Moderate Regionally restricted euxassay_007630_20
Specimen euxassay_007630_21: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: extrinsic ocular muscle Moderate Regionally restricted euxassay_007630_21
TS23: lung Moderate Regionally restricted euxassay_007630_21
TS23: saccule Strong Regionally restricted euxassay_007630_21
TS23: axial muscle Moderate Regionally restricted euxassay_007630_21
TS23: anterior abdominal wall muscle Moderate Regionally restricted euxassay_007630_21
TS23: telencephalon mantle layer Weak Regionally restricted euxassay_007630_21
TS23: telencephalon ventricular layer Weak Regionally restricted euxassay_007630_21
Specimen euxassay_007630_22: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: extrinsic ocular muscle Moderate Regionally restricted euxassay_007630_22
TS23: lung Moderate Regionally restricted euxassay_007630_22
TS23: axial muscle Moderate Regionally restricted euxassay_007630_22
TS23: anterior abdominal wall muscle Moderate Regionally restricted euxassay_007630_22
Specimen euxassay_007630_23: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: extrinsic ocular muscle Moderate Regionally restricted euxassay_007630_23
TS23: saccule Moderate Regionally restricted euxassay_007630_23
TS23: axial muscle Moderate Regionally restricted euxassay_007630_23
TS23: anterior abdominal wall muscle Moderate Regionally restricted euxassay_007630_23
Contributing Projects:
Mouse Genome Database (MGD), Gene Expression Database (GXD), Mouse Models of Human Cancer database (MMHCdb) (formerly Mouse Tumor Biology (MTB)), Gene Ontology (GO)
Citing These Resources
Funding Information
Warranty Disclaimer, Privacy Notice, Licensing, & Copyright
Send questions and comments to User Support. 		last database update
12/10/2024
MGI 6.24 		The Jackson Laboratory
