Gene Expression Data
Assay Details
Assay
|
Reference:
|
J:108556
Buttler K, et al., Mesenchymal cells with leukocyte and lymphendothelial characteristics in murine embryos. Dev Dyn. 2006 Jun;235(6):1554-1562
|
Assay type:
|
Immunohistochemistry
|
MGI Accession ID:
|
MGI:5551773
|
Gene symbol:
|
Lyve1
|
Gene name:
|
lymphatic vessel endothelial hyaluronan receptor 1
|
|
Results
|
Specimen
5A,B:
embryonic day 10.5
(more )
Note: Double labeled: red - Lyve1; green - Ptprc (CD45; assay MGI:5551777).
Specimen
5A,B:
(close )
Genetic Background:
|
NMRI
|
Age:
|
embryonic day 10.5
|
Sex:
|
Not Specified
|
Type:
|
section
|
Embedding:
|
Cryosection
|
Note:
|
Double labeled: red - Lyve1; green - Ptprc (CD45; assay MGI:5551777).
|
Structure |
Level |
Pattern |
Image |
Note |
TS17: neural tube |
Absent |
|
5A
|
|
TS17: mediastinum |
Present |
Regionally restricted |
5B
,
5A
|
The mediastinal region contained cells co-expressing Lyve1 and CD45/Ptprc and single immunopositive cells of both types.
|
Specimen
5C:
embryonic day 11.5
(more )
Note: Double labeled: red - Lyve1; green - Ptprc (CD45; assay MGI:5551777).
Specimen
5C:
(close )
Genetic Background:
|
NMRI
|
Age:
|
embryonic day 11.5
|
Sex:
|
Not Specified
|
Type:
|
section
|
Embedding:
|
Cryosection
|
Note:
|
Double labeled: red - Lyve1; green - Ptprc (CD45; assay MGI:5551777).
|
Structure |
Level |
Pattern |
Image |
Note |
TS19: dermatome |
Present |
Regionally restricted |
5C
|
Lyve1 and CD45 double positive cells were detected in dermatomes laterally from the neural tube.
|
TS19: mediastinum |
Present |
Regionally restricted |
5C
|
The number of cells co-expressing Lyve1/CD45 in the mediastinum was greater at E11.5.
|
TS19: neural tube |
Absent |
|
5C
|
|
Specimen
6A,B:
embryonic day 12.5
(more )
Note: Double labeled: red - Lyve1; green - Ptprc (CD45; assay MGI:5551777).
Specimen
6A,B:
(close )
Genetic Background:
|
NMRI
|
Age:
|
embryonic day 12.5
|
Sex:
|
Not Specified
|
Type:
|
section
|
Embedding:
|
Cryosection
|
Note:
|
Double labeled: red - Lyve1; green - Ptprc (CD45; assay MGI:5551777).
|
Structure |
Level |
Pattern |
Image |
Note |
TS20: dermis |
Present |
Regionally restricted |
6B
,
6A
|
Lyve1 and CD45/Ptprc double immunopositive cells were detected.
|
TS20: mediastinum |
Present |
Regionally restricted |
6B
,
6A
|
Lyve1 and CD45/Ptprc double immunopositive cells were detected.
|
Specimen
6C,D:
embryonic day 13.5
(more )
Note: Double labeled: red - Lyve1; green - Ptprc (CD45; assay MGI:5551777).
Specimen
6C,D:
(close )
Genetic Background:
|
NMRI
|
Age:
|
embryonic day 13.5
|
Sex:
|
Not Specified
|
Type:
|
section
|
Embedding:
|
Cryosection
|
Note:
|
Double labeled: red - Lyve1; green - Ptprc (CD45; assay MGI:5551777).
|
Structure |
Level |
Pattern |
Image |
Note |
TS21: lymphatic system |
Present |
Regionally restricted |
6D
,
6C
|
Lyve1/CD45 double immunopositive cells with a flat morphology were detected in the lining of lymphatic vessels.
|
Specimen
8:
embryonic day 11.5
(more )
Note: Double labeled: red - Lyve1; green - Pecam1 (assay MGI:5551826).
Specimen
8:
(close )
Genetic Background:
|
NMRI
|
Age:
|
embryonic day 11.5
|
Sex:
|
Not Specified
|
Type:
|
section
|
Embedding:
|
Cryosection
|
Note:
|
Double labeled: red - Lyve1; green - Pecam1 (assay MGI:5551826).
|
Structure |
Level |
Pattern |
Image |
Note |
TS19: lymphatic system |
Present |
Regionally restricted |
8
|
Co-expression with CD31/Pecam1 was detected in the jugular lymph sac.
|
TS19: dermatome |
Present |
Scattered |
8
|
|
Specimen
9A,B,C:
embryonic day 12.5
(more )
Note: Double labeled: red - Lyve1; green - Pecam1 (assay MGI:5551826).
Specimen
9A,B,C:
(close )
Genetic Background:
|
NMRI
|
Age:
|
embryonic day 12.5
|
Sex:
|
Not Specified
|
Type:
|
section
|
Embedding:
|
Cryosection
|
Note:
|
Double labeled: red - Lyve1; green - Pecam1 (assay MGI:5551826).
|
Structure |
Level |
Pattern |
Image |
Note |
TS20: dermis |
Present |
Scattered |
9B
,
9A
|
Some co-expression with CD31/Pecam1 was observed in the scattered Lyve1 immunopositive cells. The closer to the jugular lymph sac, the stronger the CD31 co-expression.
|
TS20: mediastinum |
Present |
Scattered |
9A
,
9C
|
Some co-expression with CD31/Pecam1 was observed in the scattered Lyve1 immunopositive cells. The closer to the jugular lymph sac, the stronger the CD31 co-expression.
|
Specimen
Table 1 E10.5 Lyve1/CD31:
embryonic day 10.5
(more )
Note: Double labeled: red - Lyve1; green - Pecam1 (assay MGI:5551826).
Specimen
Table 1 E10.5 Lyve1/CD31:
(close )
Genetic Background:
|
NMRI
|
Age:
|
embryonic day 10.5
|
Sex:
|
Not Specified
|
Type:
|
section
|
Embedding:
|
Cryosection
|
Note:
|
Double labeled: red - Lyve1; green - Pecam1 (assay MGI:5551826).
|
Specimen
Table 1 E11.5 Lyve1/CD31:
embryonic day 11.5
(more )
Note: Double labeled: red - Lyve1; green - Pecam1 (assay MGI:5551826).
Specimen
Table 1 E11.5 Lyve1/CD31:
(close )
Genetic Background:
|
NMRI
|
Age:
|
embryonic day 11.5
|
Sex:
|
Not Specified
|
Type:
|
section
|
Embedding:
|
Cryosection
|
Note:
|
Double labeled: red - Lyve1; green - Pecam1 (assay MGI:5551826).
|
Specimen
Table 1 E12.5 Lyve1/CD31:
embryonic day 12.5
(more )
Note: Double labeled: red - Lyve1; green - Pecam1 (assay MGI:5551826).
Specimen
Table 1 E12.5 Lyve1/CD31:
(close )
Genetic Background:
|
NMRI
|
Age:
|
embryonic day 12.5
|
Sex:
|
Not Specified
|
Type:
|
section
|
Embedding:
|
Cryosection
|
Note:
|
Double labeled: red - Lyve1; green - Pecam1 (assay MGI:5551826).
|
Specimen
Table 1 E13.5 Lyve1/CD31:
embryonic day 13.5
(more )
Note: Double labeled: red - Lyve1; green - Pecam1 (assay MGI:5551826).
Specimen
Table 1 E13.5 Lyve1/CD31:
(close )
Genetic Background:
|
NMRI
|
Age:
|
embryonic day 13.5
|
Sex:
|
Not Specified
|
Type:
|
section
|
Embedding:
|
Cryosection
|
Note:
|
Double labeled: red - Lyve1; green - Pecam1 (assay MGI:5551826).
|
Specimen
Table 1 E10.5 Lyve1/CD45:
embryonic day 10.5
(more )
Note: Double labeled: red - Lyve1; green - Ptprc (CD45; assay MGI:5551777).
Specimen
Table 1 E10.5 Lyve1/CD45:
(close )
Genetic Background:
|
NMRI
|
Age:
|
embryonic day 10.5
|
Sex:
|
Not Specified
|
Type:
|
section
|
Embedding:
|
Cryosection
|
Note:
|
Double labeled: red - Lyve1; green - Ptprc (CD45; assay MGI:5551777).
|
Specimen
Table 1 E11.5 Lyve1/CD45:
embryonic day 11.5
(more )
Note: Double labeled: red - Lyve1; green - Ptprc (CD45; assay MGI:5551777).
Specimen
Table 1 E11.5 Lyve1/CD45:
(close )
Genetic Background:
|
NMRI
|
Age:
|
embryonic day 11.5
|
Sex:
|
Not Specified
|
Type:
|
section
|
Embedding:
|
Cryosection
|
Note:
|
Double labeled: red - Lyve1; green - Ptprc (CD45; assay MGI:5551777).
|
Specimen
Table 1 E12.5 Lyve1/CD45:
embryonic day 12.5
(more )
Note: Double labeled: red - Lyve1; green - Ptprc (CD45; assay MGI:5551777).
Specimen
Table 1 E12.5 Lyve1/CD45:
(close )
Genetic Background:
|
NMRI
|
Age:
|
embryonic day 12.5
|
Sex:
|
Not Specified
|
Type:
|
section
|
Embedding:
|
Cryosection
|
Note:
|
Double labeled: red - Lyve1; green - Ptprc (CD45; assay MGI:5551777).
|
Specimen
Table 1 E13.5 Lyve1/CD45:
embryonic day 13.5
(more )
Note: Double labeled: red - Lyve1; green - Ptprc (CD45; assay MGI:5551777).
Specimen
Table 1 E13.5 Lyve1/CD45:
(close )
Genetic Background:
|
NMRI
|
Age:
|
embryonic day 13.5
|
Sex:
|
Not Specified
|
Type:
|
section
|
Embedding:
|
Cryosection
|
Note:
|
Double labeled: red - Lyve1; green - Ptprc (CD45; assay MGI:5551777).
|
|
