Probe:	PCP2 probe1
Probe preparation:	Antisense labelled with S35 RNA
Visualized with:	Autoradiography

Structure	Level	Pattern	Image	Note
TS20: cerebral cortex	Present	Regionally restricted	8A/B	Expression in neuroepithelium of cerebral cortex, and posterior hypothalamus.
TS20: hypothalamus	Present	Regionally restricted	8A/B	Expression in neuroepithelium of cerebral cortex, and posterior hypothalamus.
TS20: telencephalon subventricular zone	Present	Regionally restricted	8A/B	Expression in subventricular zone of pallidum.
TS20: olfactory epithelium	Present		8A/B	Limited expression in olfactory epithelium of nasal cavity, epithelium lining oral cavity, oropharynx and intestine.
TS20: oral epithelium	Present		8A/B	Limited expression in olfactory epithelium of nasal cavity, epithelium lining oral cavity, oropharynx and intestine.
TS20: oropharynx	Present		8A/B	Limited expression in olfactory epithelium of nasal cavity, epithelium lining oral cavity, oropharynx and intestine.
TS20: ventricular layer	Strong	Regionally restricted	8A/B	High expression levels in upper and lower plate of ependymal layer of neural tube.
TS20: intestine epithelium	Strong		8A/B
TS20: stomach epithelium	Strong		8A/B
TS20: lung	Absent		8A/B

Structure	Level	Pattern	Image	Note
TS22: brain meninges	Strong		8D/E
TS22: lung	Present		8D/E	Expression first detected lungs.
TS22: intestine epithelium	Weak		8D/E	Significantly decreased expression in epithelial layers of stomach and intestine.
TS22: stomach epithelium	Weak		8D/E	Significantly decreased expression in epithelial layers of stomach and intestine.
TS22: maturing glomerular tuft	Strong		8D/E

Structure	Level	Pattern	Image	Note
TS24: vibrissa follicle	Strong		8G/H
TS24: bone	Strong	Regionally restricted	8G/H	Abundant expression in periostal collar of bone.
TS24: lung	Strong		8G/H
TS24: intestine epithelium	Weak		8G/H	Significantly decreased expression in epithelial layers of stomach and intestine.
TS24: stomach epithelium	Weak		8G/H	Significantly decreased expression in epithelial layers of stomach and intestine.
TS24: maturing glomerular tuft	Strong		8G/H

Structure	Level	Pattern	Image	Note
TS26: enamel organ	Present		8K/L
TS26: nasal cavity epithelium	Strong		8K/L
TS26: lung	Weak		8K/L
TS26: intestine epithelium	Absent		8K/L	Authors state expression in epithelial layers of stomach and intestine was almost completely detectable.
TS26: stomach epithelium	Absent		8K/L	Authors state expression in epithelial layers of stomach and intestine was almost completely detectable.

Structure	Level	Pattern	Image	Note
TS22: lens fiber	Strong		9A1/A2
TS22: neural retina	Weak	Regionally restricted	9A1/A2	Lower expression in inner nuclear layer of neural retina.

Structure	Level	Pattern	Image	Note
TS26: retina inner nuclear layer	Weak			Diminished expression in the inner nuclear layer of the neural retina.

Structure	Level	Pattern	Image	Note
TS26: nasal cavity epithelium	Strong		9B1/B2
TS26: intestine epithelium	Absent		9B1/B2	Authors state expression in epithelial layers of stomach and intestine was almost completely detectable.
TS26: stomach epithelium	Absent		9B1/B2	Authors state expression in epithelial layers of stomach and intestine was almost completely detectable.

Structure	Level	Pattern	Image	Note
TS26: esophagus	Present		9C1/C2

Structure	Level	Pattern	Image	Note
TS26: cochlear duct	Present		9D1/D2

Structure	Level	Pattern	Image	Note
TS26: enamel organ	Present		9E1/E2

Structure	Level	Pattern	Image	Note
TS28: cortical amygdaloid nucleus	Strong		10C/F
TS28: lateral amygdaloid nucleus	Strong		10C/F
TS28: thalamic nucleus	Strong	Regionally restricted	10C/F	Strong expression in nuclei in the mediate thalamus.
TS28: lateral habenular nucleus	Strong		10C/F
TS28: medial habenular nucleus	Strong		10C/F
TS28: amygdala	Weak	Regionally restricted	10C/F	Low levels of expression in intragranular part of cortical plate of cingulate and, at even lesser intensity, in the central cortex and amygdala.
TS28: cingulate cortex	Weak	Regionally restricted	10C/F	Low levels of expression in intragranular part of cortical plate of cingulate and, at even lesser intensity, in the central cortex and amygdala.
TS28: neocortex	Weak	Regionally restricted	10C/F	Low levels of expression in intragranular part of cortical plate of cingulate and, at even lesser intensity, in the central cortex and amygdala.
TS28: hippocampus CA1	Strong		10C/F
TS28: hippocampus CA2	Strong		10C/F
TS28: subiculum	Strong		10C/F
TS28: dentate gyrus	Absent		10C/F
TS28: hippocampus CA3	Absent		10C/F

Structure	Level	Pattern	Image	Note
TS28: cerebral cortex subventricular zone	Present		11E/F
TS28: hippocampus CA1	Strong		11E/F
TS28: hippocampus CA2	Strong		11E/F
TS28: subiculum	Strong		11E/F
TS28: pontine nucleus	Strong	Regionally restricted	11E/F	High levels of expression in pontine gray nucleus,
TS28: interpeduncular nucleus	Strong		11E/F
TS28: cerebellum granule cell layer	Present		11E/F
TS28: cerebellum white matter	Absent		11E/F

Structure	Level	Pattern	Image	Note
TS28: hippocampus CA1	Strong		12C
TS28: hippocampus CA2	Strong		12C
TS28: subiculum	Strong		12C

Structure	Level	Pattern	Image	Note
TS28: cerebellum granule cell layer	Present		12F
TS28: cerebellum white matter	Absent
