Gene Expression Data
Assay Details
Assay
Reference: J:264612 Morgani SM, et al., A Sprouty4 reporter to monitor FGF/ERK signaling activity in ESCs and mice. Dev Biol. 2018 Sep 1;441(1):104-126
Assay type: RNA in situ
MGI Accession ID: MGI:6286488
Gene symbol: Spry4
Gene name: sprouty RTK signaling antagonist 4
Results
Specimen 9C: embryonic day 10.5 (more )
Structure Level Pattern Image Note
TS17: 1st branchial arch mandibular component Present 9C
TS17: 1st branchial arch maxillary component Present 9C
TS17: fronto-nasal process Present 9C
TS17: midbrain-hindbrain junction Present 9C
Specimen S7A E7.5: embryonic day 7.5 (more )
Structure Level Pattern Image Note
TS11: primitive endoderm Absent S7A E7.5
TS11: primitive streak Present S7A E7.5 Expression was detected in cells exiting the primitive streak.
Specimen S7A E8.0: embryonic day 8.0 (more )
Structure Level Pattern Image Note
TS12: primitive endoderm Absent S7A E8.0
TS12: primitive streak Present S7A E8.0 Expression was detected in cells exiting the primitive streak.
Specimen S7A E9.0: embryonic day 9.0 (more )
Structure Level Pattern Image Note
TS15: 1st branchial arch Present S7A E9.0
TS15: 2nd branchial arch Present S7A E9.0
TS15: somite Present S7A E9.0
TS15: tail unsegmented mesenchyme Present S7A E9.0
Specimen S7A E9.5: embryonic day 9.5 (more )
Structure Level Pattern Image Note
TS15: 1st branchial arch Present S7A E9.5
TS15: somite Present S7A E9.5
TS15: tail unsegmented mesenchyme Present S7A E9.5
Specimen S7A E10.5: embryonic day 10.5 (more )
Structure Level Pattern Image Note
TS17: somite Present S7A E10.5
TS17: tail unsegmented mesenchyme Present S7A E10.5
Specimen S7B1: embryonic day 8.0 (more )
Structure Level Pattern Image Note
TS12: primitive streak Present S7B1
Specimen S7B2: embryonic day 8.0 (more )
Structure Level Pattern Image Note
TS12: primitive streak Present S7B2
Specimen S7C left: embryonic day 9.0 (more )
Structure Level Pattern Image Note
TS14: 1st branchial arch Present S7C left
TS14: 2nd branchial arch Present S7C left
Specimen S7C middle: embryonic day 9.0 (more )
Structure Level Pattern Image Note
TS14: 2nd branchial arch Present S7C middle
Specimen S7C right: embryonic day 9.0 (more )
Structure Level Pattern Image Note
TS14: somite Present S7C right
Specimen S7D pharyngeal arches: embryonic day 10.5 (more )
Structure Level Pattern Image Note
TS17: 1st branchial arch Present S7D pharyngeal arches
TS17: 2nd branchial arch Present S7D pharyngeal arches
Specimen S7D limb bud: embryonic day 10.5 (more )
Structure Level Pattern Image Note
TS17: limb mesenchyme Present S7D Limb bud
Specimen S8A: embryonic day 12.5 (more )
Structure Level Pattern Image Note
TS20: forelimb digit Absent S8A
TS20: hand Present Regionally restricted S8A Expression was detected at the distal edge of the forepaw.
Specimen S8B sagittal: embryonic day 12.5 (more )
Structure Level Pattern Image Note
TS20: hand Present Regionally restricted S8B Sagittal Expression was detected at the distal edge of the forepaw.
Specimen S8B transverse: embryonic day 12.5 (more )
Structure Level Pattern Image Note
TS20: hand Present Regionally restricted S8B Transverse Expression was detected at the distal edge of the forepaw.
