Probe:	Lmo3 probe
Probe preparation:	Antisense labelled with digoxigenin RNA

Structure	Level	Pattern	Image	Note
TS26: amygdala	Strong	Regionally restricted	3C	Expressed in the lateral and basolateral nuclei as an almond-like shape.

Structure	Level	Pattern	Image	Note
TS26: amygdala	Strong	Regionally restricted	3D	Expressed in the lateral and basolateral nuclei as an triangle-like shape in the mutant.

Structure	Level	Pattern	Image	Note
TS28: basolateral amygdaloid nucleus	Strong		5B
TS28: lateral amygdaloid nucleus	Strong		5B

Structure	Level	Pattern	Image	Note
TS28: amygdala	Present	Regionally restricted	5F	Greatly diminished and was expressed only in a small number of cells in the presumptive amygdala region.

Structure	Level	Pattern	Image	Note
TS27: basolateral amygdaloid nucleus	Present		6A
TS27: lateral amygdaloid nucleus	Present		6A

Structure	Level	Pattern	Image	Note
TS27: basolateral amygdaloid nucleus	Present		6B
TS27: lateral amygdaloid nucleus	Present		6B

Structure	Level	Pattern	Image	Note
TS28: basolateral amygdaloid nucleus	Present		6C
TS28: lateral amygdaloid nucleus	Present		6C

Structure	Level	Pattern	Image	Note
TS28: basolateral amygdaloid nucleus	Present		6D
TS28: lateral amygdaloid nucleus	Present		6D

Structure	Level	Pattern	Image	Note
TS27: basolateral amygdaloid nucleus	Present		6E	Expression was not significantly affected in the mutant.
TS27: lateral amygdaloid nucleus	Present		6E	Expression was not significantly affected in the mutant.

Structure	Level	Pattern	Image	Note
TS27: basolateral amygdaloid nucleus	Weak	Scattered	6F	Positive cells were scattered throughout the field of view at a low density in the mutant.
TS27: lateral amygdaloid nucleus	Weak	Scattered	6F	Positive cells were scattered throughout the field of view at a low density in the mutant.

Structure	Level	Pattern	Image	Note
TS28: basolateral amygdaloid nucleus	Weak		6G	Expression was greatly reduced and remained at a level similar to that prevailing in these mutant mice at P24.
TS28: lateral amygdaloid nucleus	Weak		6G	Expression was greatly reduced and remained at a level similar to that prevailing in these mutant mice at P24.

Structure	Level	Pattern	Image	Note
TS28: basolateral amygdaloid nucleus	Weak		6H	Expression was greatly reduced and remained at a level similar to that prevailing in these mutant mice at P24.
TS28: lateral amygdaloid nucleus	Weak		6H	Expression was greatly reduced and remained at a level similar to that prevailing in these mutant mice at P24.
