SchemaSpy - Table pub.mgd.gxd

Defines Genotype of animal used for Gel Lane or Specimen using Strain information.

See GXD_GelLane, GXD_Specimen, GXD_AllelePair.

Generated by
SchemaSpy

Legend:

Primary key columns

Columns with indexes

Implied relationships

Excluded column relationships

< n > number of related tables

Column

Type

Size

Nulls

Auto

Default

Children

Parents

Comments

_genotype_key

serial

√

nextval('gxd_genotype_seq'::regclass)

gxd_allelegenotype._genotype_key	gxd_allelegenotype__genotype_key_fkey C
gxd_allelepair._genotype_key	gxd_allelepair__genotype_key_fkey C
gxd_expression._genotype_key	gxd_expression__genotype_key_fkey R
gxd_gellane._genotype_key	gxd_gellane__genotype_key_fkey R
gxd_htsample._genotype_key	gxd_htsample__genotype_key_fkey R
gxd_htsample_rnaseqset._genotype_key	gxd_htsample_rnaseqset__genotype_key_fkey R
gxd_specimen._genotype_key	gxd_specimen__genotype_key_fkey R
mrk_do_cache._genotype_key	mrk_do_cache__genotype_key_fkey C
prb_strain_genotype._genotype_key	prb_strain_genotype__genotype_key_fkey R

primary key

_strain_key

int4

prb_strain._strain_key

gxd_genotype__strain_key_fkey R

foreign key to PRB_Strain

isconditional

int2

is this a conditional genotype?

note

text

2147483647

√

null

note

_existsas_key

int4

voc_term._term_key

gxd_genotype__existsas_key_fkey R

foreign key to VOC_Term where _Vocab_key = 60 (Genotype Exists As); this genotype exists as 'Mouse Line', 'Cell Line', 'Chimeric', 'Not Specified', 'Not Applicable'

_createdby_key

int4

1001

mgi_user._user_key

gxd_genotype__createdby_key_fkey R

user who created the record

_modifiedby_key

int4

1001

mgi_user._user_key

gxd_genotype__modifiedby_key_fkey R

user who last modified the record

creation_date

timestamp

29,6

now()

date record was created

modification_date

timestamp

29,6

now()

date record was last modified

Table contained 96,729 rows at Mon Sep 11 06:12 EDT 2023

Indexes:

Column(s)	Type	Sort	Constraint Name
_genotype_key	Primary key	Asc	gxd_genotype_pkey
_createdby_key	Performance	Asc	gxd_genotype_idx_createdby_key
creation_date	Performance	Asc	gxd_genotype_idx_creation_date
_existsas_key	Performance	Asc	gxd_genotype_idx_existsas_key
modification_date	Performance	Asc	gxd_genotype_idx_modification_date
_modifiedby_key	Performance	Asc	gxd_genotype_idx_modifiedby_key
_strain_key	Performance	Asc	gxd_genotype_idx_strain_key
